PRODUCT
材料：玻璃纖維增強塑料;框葉PBT UL 94V-0等級
直流鼓風機
產品描述
Product Description
SIZE:40x40x10mm
CONSTRUCTION:Glass Fiber reinforced plastic; Impeller and housing PBT are UL 94V-0 rating
OPERATING TEMPERATURE:Ball bearing -10℃ to +70℃;CycleSeal bearing -10℃ to +70℃
INSULATION RESISTANCE:10meg Ohm min, at 500 VDC(between frame and terminal)
DIELECTRIC STRENGTH:5mA max, at 500 VAC 60Hz one minute(between frame and terminal)
FUNCTION OPTIONS:FG,RD, PWM,Auto Restart, Polarity Protection
尺寸圖
Dimensions Drawing
特徵曲線(xiàn )
Characteristic Curves
規格參數
Specifications
| Model | Bearing Type | Rated Voltage | urrent | Speed | Air Flow | Static Pressure | Noise Level | Weight |
| VDC | A | RPM | CFM | mmH₂O | dBA | g | ||
| YBD4010X05 | C or B | 5 | 0.16 | 6500 | 1.90 | 4.76 | 28.43 | 11.5 |
| YBH4010X05 | C or B | 5 | 0.14 | 5500 | 1.61 | 3.41 | 24.80 | 11.5 |
| YBM4010X05 | C or B | 5 | 0.10 | 4500 | 1.32 | 2.28 | 20.50 | 11.5 |
| YBL4010X05 | C or B | 5 | 0.07 | 4000 | 1.17 | 1.80 | 17.80 | 11.5 |
| YBD4010X12 | C or B | 12 | 0.10 | 7000 | 2.04 | 5.53 | 30.05 | 11.5 |
| YBH4010X12 | C or B | 12 | 0.08 | 6000 | 1.75 | 4.06 | 26.70 | 11.5 |
| YBM4010X12 | C or B | 12 | 0.06 | 5000 | 1.46 | 2.82 | 22.70 | 11.5 |
| YBL4010X12 | C or B | 12 | 0.05 | 4000 | 1.17 | 1.80 | 17.80 | 11.5 |
1.Specifications subject to change without notiec;
2.Design and provide products according to client’s requirements.
